ATO Load Cell Amplifier with Digital Display - High Precision Weight Indicator Controller with 4-20mA Output - Ideal for Industrial Scales, Packaging Machines & Laboratory Equipment

Packing List Include: 1 ×Load Cell Amplifier 1 ×User manual ATO Load Cell Amplifier with 6-digit LED display, output signal 4-20mA/ 0-10V/ RS485(Modbus-RTU)/ 4-20mA & RS485/ 0-10V & RS485. It can be used as a load cell indicator for reading the weight values. There are 3 keys for parameter settings. Digital load cell amplifier can be calibrated on-line by its 3 keys. The setting parameters include zero, capacity, communication rate, division value, decimal digits, etc. How to restore factory settings When setting error, you can press K2 key to restore factory setting, free from maloperation. Step 1: Power off → long press K2 Step 2: Power on → wait 2 seconds, then release K2 Specification Model ATO-S-LCTR-DY610 Accuracy ±0.2%FS ±1 byte Input signal 0~±20mV Excitation voltage DC 5V (for load cell) Output signal * (optional) DC 4-20mA,DC 0-10V, RS485 (Modbus-RTU), 4-20mA & RS485, 0-10V & RS485 Sampling rate 20 times/s, 80 times/s Power supply DC 12-30V Power consumption ＜1W Display 6 digit red LED, -99999~999999 Readout units kg, g, ton, and newtons Protection class IP65 ATO Load cell Amplifier wiring diagram : The shield of the load cell can be connected to the amplifier's E- terminal together. Beam Load Cell, 100 kg Junction Box Amplifier, output 0-10V & RS485 Amplifier, output 4-20mA & RS485 Button Type Load Cell, 5 kg Spoke Type Load Cell, 300 kg Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart Customer Reviews 5.0 out of 5 stars 1 4.8 out of 5 stars 3 3.5 out of 5 stars 6 3.5 out of 5 stars 6 4.0 out of 5 stars 1 4.1 out of 5 stars 3 Price $96.80$96.80 $66.99$66.99 $119.77$119.77 $119.77$119.77 $134.99$134.99 $116.10$116.10 load cell ✓ no data no data no data ✓ ✓ Junction Box no data ✓ no data no data no data no data Load Cell Amplifier no data no data ✓ ✓ no data no data

【Digital Dispaly】ATO load cell amplifier with 6-digit LED screen, it can directly show the readings of load cells

【Standard signal】Accuracy ±0.2%FS , input signal 0~±20mV, output signal 4-20mA

【Output Readout】The digital load cell controller can be set up to different units, including kg, g, ton, and newtons

【Parameter Setting】There are 3 keys for parameter settings, the load cell indicator can be calibrated on-line by its 3 keys, the setting parameters include zero, capacity, communication rate, division value, decimal digits, etc.

【Customer Service】If you are not sure about the size or have any issue about the product or service, please don't hesitate to email us. We will answer you within 12h
